Specification

Power	0.37 kW - 1.5 kW (0.5 HP - 2.0 HP)
Frequency	50 Hz
Speed	2880 rpm
Versions	Single Phase, 180 - 240 V, 50 Hz 2&3 phase, 380V - 415V, 50 Hz Low Voltage 95 V - 175 V
Type	Capacitor start and run type
Maximum Flow Rate	600 lph
Head Range	6 mts to 28 mts
Class of Insulation	B
Direction of Rotation	Clockwise from driving end
Type of Duty	S1 (Continuous)
Pipe Size(mm) (Suction x Delivery)	(25x25) (32x25) (40x40) (50x40) (50x50) (65x50) (75x65) (75x75)

Material of Construction

COMPONENT	MATERIAL
Motor Frame	Cast Iron
Pump Casing	Cast Iron
Bearing	Double sealed precesion ball bearings
Impeller	Cast Iron
Seal	Mechanical seal with high alumina seal face
Shaft	EN 8
Winding Wire	Enameled copper
