Specification

Power	0.37 kW - 1.1 kW (0.5 HP - 1.5 HP)
Frequency	50 Hz
Speed	2880 rpm
Versions	Single Phase, 180 - 240 V, 50 Hz, AC
Type	Capacitor start and run type
Flow Range	5 lph to 50 lph
Maximum Delivery Head	25 mts
Class of Insulation	B
Direction of Rotation	Clockwise from driving end
Type of Duty	S1 (Continuous)
Pipe Size(mm) (Suction x Pressure x Delivery)	(32x25x25), (40x32x25)

Material of Construction

COMPONENT	MATERIAL
Motor Frame	Cast Iron/Aluminium
Pump Casing	Cast Iron
Bearing	Double sealed precesion ball bearings
Impeller	Cast Iron
Seal	Mechanical seal with high alumina seal face
Shaft	EN 8 (Motor side) + SS (Pump side)
Winding Wire	Enameled copper
